MIL-DTL-45195 Cartridge, 105Mm, He, M1 Loading, Assembling And PackingThis specification covers the requirements, examinations and tests for the loading, assembling and packing of Projectile, 105MM, HE, M1 for use with the 105MM Howitzer M101, M102 and M119\(see 6.1\), M2A1, M2A2, M103, and M137 with TNT, composition B or IMX-101.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21 - 22 - 23


MIL-DTL-45195F (AR)
3.2.1 Projectile loading assembly (prior to loading
explosive).  The components and assemblies shall comply with
all requirements specified on dwg. 9211610.
3.2.2 Projectile loading assembly (Radiographic acceptance
requirements).  The components and assemblies shall comply with
all requirements specified on dwg. 9211610.
3.2.3 Projectile loading assembly (prior to assembly of
liner).  The components and assemblies shall comply with all
requirements specified on dwg. 9211610.
3.2.4 Projectile, 105MM, HE, M1 LAP (prior to assembly of
supplementary charge).  The components and assemblies shall
comply with all requirements specified on dwg. 9211610.
3.2.5 Projectile 105MM, HE, M1 LAP (prior to assembly of
closing plug).  The components and assemblies shall comply
with all requirements specified on dwg. 9211610.
3.2.6 Primer (prior to assembly to case).  The components
and assemblies shall comply with all requirements specified on
dwg. 8838130 or 8838129.
3.2.7 Cartridge case (prior to assembling propelling
charge). The components and assemblies shall comply with all
requirements specified on dwg. 8595386, 7548409 or 7548025.
3.2.8 Propelling charge (prior to assembly into cartridge
case).  The components and assemblies shall comply with all
requirements specified on dwg. 9205472.
3.2.9 Cartridge case with propelling charge.  The
components and assemblies shall comply with all requirements
specified on dwg. 9211611
3.2.10 Projectile and cartridge case assemblies (prior to
pack). The components and assemblies shall comply with all
requirements specified on dwg. 9211611
3.2.11 Unsealed fiber container. The components and
assemblies shall comply with all requirements specified on
dwg. 7549073.
3.2.12 Sealed fiber container. The components and
assemblies shall comply with all requirements specified on
dwg. 7549073.
3.2.13 Sealed wood packaging box.  The components and
assemblies shall comply with all requirements specified on
dwg. 7549072.
