MIL-DTL-45195F (AR)
Conformance inspection by classification of characteristics
PARAGRAPH
TITLE
DRAWING NUMBER
SHEET 1 OF 3
4.3.2.2
Projectile loading assembly (Before post cycle
9211610
heating)
NEXT HIGHER
(Radiographic acceptance requirements)
ASSEMBLY
9211611
CLASSIFICAT
EXAMINATION OR TEST
CONFORMANCE
REQUIREMENT
INSPECTION
ION
CRITERIA
PARAGRAPH
METHOD
REFERENCE
Critical
1
Base separation in excess of 0.015"
100%
3.5.3
4.4.3
(see 6.16.1)
2
Cavities, other than piping, cracks
100%
3.5.5
4.4.3
or annular rings in Segment A with a
total area in excess of 1/16 square
inch or length in excess of 1/4 inch
(see 6.16.2)
3
Annular rings in Segment A or B with
100%
3.5.8
4.4.3
a width in excess of 1/32 inch
(see 6.16.3)
4
Piping cavities in Segment A
100%
3.5.6
4.4.3
exceeding 1/16 square inch in total
area or 1/8 inch in width
(see 6.16.4)
5
Cracks in Segment A in excess of the
100%
3.5.7.1
4.4.3
requirements of Table I (see 6.16.5)
18
