MIL-DTL-45195F (AR)
Conformance inspection by classification of characteristics
PARAGRAPH
TITLE
DRAWING NUMBER
SHEET 1 OF 1
4.3.2.4
Projectile, 105MM, HE, M1 LAP (prior to
9211610
assembly of supplementary charge)
NEXT HIGHER
ASSEMBLY
9211611
CLASSIFICAT
EXAMINATION OR TEST
CONFORMANCE
REQUIREMENT
INSPECTION
ION
CRITERIA
PARAGRAPH
METHOD
REFERENCE
Critical
None defined
Major
101
Depth to bottom of liner min.
Level IV
3.2.4
AIE
102
True position of inside diameter of
Level IV
3.2.4
AIE
liner with minor diameter of internal
thread and end face of projectile
body
103
Inside diameter of liner after
Level IV
3.2.4
AIE
swaging
104
Torque of liner (witnessed during
Level IV
3.2.4
AIE/Visual
application of assembly torque)
105
Swage missing or incomplete
100%
3.2.4
Visual
106
Presence of caked explosive, stain or
100%
3.11
Visual
bloom on exterior of shell body, and
forward face
Minor
201
Liner damaged
Level II
3.2.4
Visual
202
Foreign material in liner cavity
Level II
3.10
Visual
including explosive
203
Evidence of poor workmanship
Level II
3.13
Visual
22
