MIL-DTL-45195F (AR)
Conformance inspection by classification of characteristics
DRAWING NUMBER
PARAGRAPH
TITLE
SHEET 3 OF 3
9211610
4.3.2.2
Projectile loading assembly (Before post
cycle heating)
NEXT HIGHER
(Radiographic acceptance requirements)
ASSEMBLY
9211611
CLASSIFICATI
EXAMINATION OR TEST
CONFORMANCE
REQUIREMENT
INSPECTION
ON
CRITERIA
PARAGRAPH
METHOD
REFERENCE
Major
101
Cast defects in Segments A (except
100%
3.5.4
4.4.3
cracks,) B, C or D in excess of the
through
requirements of table 1
3.5.8
102
Porous areas in excess of that
100%
3.5.4
4.4.3
permitted
103
Cracks in Segment A in excess of
100%
3.5.7.2
4.4.3
that permitted
104
Rotating band gaps in excess of that
100%
3.5.1
4.4.3
permitted
105
Any visible base separation, less
100%
3.5.3
4.4.3
than 0.015"
Minor
201
Cracks in Segments A, B and C
100%
3.5.7.2
4.4.3
combined in excess of that permitted
20
