MIL-DTL-46229D (AR)
Drawing Number
7549251
4.3.2.9
Cartridge, 105MM Blank M395 Assembly (proving ground).
Next Higher Assembly
Conformance
Requirement
Classification
Examination or Test
Inspection Method Reference
Criteria
Paragraph
Critical
1
Hang fire
\1
3.5.1
4.4.2
2
Fragments
\1
3.5.4
4.4.2
Major
Misfire
3.5.1
4.4.2
\1
101
Sound level
AIE/4.4.2
3.5.2
102
\1
Extraction
Manual/4.4.2
3.5.3
103
\1
Minor
None defined
201
\1 A quantity of 20 shall be fired for first article and 20 from the first three consecutively produced lots. If no failures occur, the
sample size shall be reduced to 10 for subsequent lots. If any subsequent lot failures occur, the 20 samples size shall be
reinstated until such time as three consecutive acceptable lots are produced. The lot shall be rejected if any major defect occurs.
Drawing Number
7549255
4.3.2.10
Fiber container (unsealed).
Next Higher Assembly
7549254
Conformance
Requirement
Classification
Examination or Test
Inspection Method Reference
Criteria
Paragraph
Critical
None defined
Major
VL-IV
3.2
Visual
Packing component missing
101
Minor
Round cannot be removed by hand
201
VL-II
3.2
Manual
VL-II
3.2
Visual
Round improperly assembled in
202
container
12
