MIL-DTL-46229D (AR)
Drawing Number
7549251
4.3.2.5
Cartridge, 105MM Blank M395 Assembly (primer case).
Next Higher Assembly
Conformance
Requirement
Classification
Examination or Test
Inspection Method Reference
Criteria
Paragraph
Critical
1
Primer above flush
100% + VL-VII
3.2
AAIE
Major
Primer loose
VL-IV
3.2
Visual/manual
101
Air pressure test of case
VL-IV
3.4
AIE
102
Minor
Foreign matter on interior
VL-II
3.6
Visual
201
Drawing Number
7549251
4.3.2.6
Cartridge, 105MM Blank M395 Assembly (prior to inserting closing wad).
Next Higher Assembly
Conformance
Requirement
Classification
Examination or Test
Inspection Method Reference
Criteria
Paragraph
Critical
None defined
Major
Black powder moisture content (see
1/
3.2
4.4.1
101
dwg 7549251)
Black powder missing or inadequate
3.2
Visual
102
VL-IV
Minor
Evidence of poor workmanship
3.6
Visual
VL-II
201
1/ Select sample in accordance with MIL-P-223. Select one (1) sample randomly from each production shift. Failure to comply
with the specified requirement shall be cause for rejection of the production shift represented by the sample.
