MIL-DTL-14852D (AR)
Conformance inspection by classification of characteristics
PARAGRAPH
TITLE
DRAWING NUMBER
4.3.2.4
Body (prior to banding)
SHEET 1 OF 4
10534902
NEXT HIGHER
ASSEMBLY
10534901
CLASSIFICATION
EXAMINATION OR TEST
CONFORMANCE
REQUIREMENT
INSPECTION
CRITERIA
PARAGRAPH
METHOD
REFERENCE
Critical
1
Metal defective
100%
3.5.1
4.4.5.1
(Note 1)
Major
101
Diameter of rotating band seat
Level
IV
3.2
AIE
102
Width of rotating band seat
Level
IV
3.2
AIE
103
Ribs missing from band seat
Level
IV
3.2
Visual
104
Scoring missing from band seat
Level
IV
3.2
Visual
105
Evidence of sand or shot blast on band
Level
IV
3.2
Visual
seat after scoring
106
Runout of pitch diameter of thread
Level IV
3.2
AIE
with bourrelets and front face
107
Runout of large cavity with bourrelets
Level IV
3.2
AIE
108
Runout of body with bourrelets
Level IV
3.2
AIE
109
Runout of base plug cavity with
Level IV
3.2
AIE
bourrelets
Note 1. The critical characteristic shall undergo 100% screening. In addition, apply Level VII
inspection IAW the critical characteristics paragraph of MIL-STD-1916.
17
