MIL-DTL-14852D (AR)
Conformance inspection by classification of characteristics
PARAGRAPH
TITLE
DRAWING NUMBER
4.3.2.6
Metal parts assembly
SHEET 1 OF 1
10534900
NEXT HIGHER
ASSEMBLY
--
CLASSIFICATION
EXAMINATION OR TEST
CONFORMANCE
REQUIREMENT
INSPECTION
CRITERIA
PARAGRAPH
METHOD
REFERENCE
Critical
None defined
Major
101
Paint in thread
Level IV
3.2
Visual
102
Paint on walls of base plug cavity
Level IV
3.2
Visual
103
Rotating band damaged
Level IV
3.2
Visual
104
Coating missing or inadequate
Level II
3.2
Visual
105
Diameter of bourrelets, max
Level IV
3.2
AIE
106
Salt spray
4.4.4
3.2
4.4.4
107
Identifying stripe missing (Note 1)
Level IV
3.2
Visual
Minor
201
Protective coating inadequate or
Level II
3.2
Visual
damaged
202
Marking missing, incorrect or illegible
level II
3.2
Visual
203
Evidence of foreign matter
Level II
3.7.1
Visual
204
Evidence of burr, sharp edges, and/or
Level II
3.7.2
Visual
cracks
205
Evidence of damaged threads
Level II
3.7.3
Visual
206
Evidence of improper painting
Level II
3.7.4
Visual/Manual
207
Improper protection of rotating band
Level II
3.7.5
Visual
Note 1. Applies to M1064 only
22
