MIL-DTL-70526B (AR)
PARAGRAPH
TITLE
DRAWING NUMBER
SHEET 1 OF 1
4.3.2.5
Delay assembly, prior to assembly of
12926809
selector cap
NEXT HIGHER
ASSEMBLY
-
CLASSIFICAT
EXAMINATION OR TEST
CONFORMANCE
REQUIREMENT
INSPECTION
ION
CRITERIA
PARAGRAPH
METHOD
REFERENCE
Critical
1
Radiographic inspection; delay column
Note 1
3.7
4.4.10
missing
Major
101
Delay closure missing or improperly
100%
3.2
Visual
Positioned.
102
Crimp on tube missing or body cracked
100%
3.2
Visual
by crimping operation
103
Outside diameter of tube, max.
Level IV
3.2
AIE
104
"O"-ring missing
Level IV
3.2
Visual
105
Gasket missing in cap
100%
3.2
Visual/AIE
106
Radiographic inspection; defects
100%
3.7
4.4.10
other than `missing delay column'
Minor
201
Evidence of poor workmanship
Level II
3.11
Visual
Note 1. 100% inspection by Level II or better certified reader with a 1 in 10 review by a
Level III certified non destructive test inspector.
14
