MIL-DTL-20354D (AR)
Conformance inspection by classification of characteristics
DRAWING NUMBER
PARAGRAPH
TITLE
SHEET 1 OF 2
9206821
4.3.2.10
Cartridge assembly
NEXT HIGHER
ASSEMBLY
CLASSIFICATION EXAMINATION OR TEST
CONFORMANCE
REQUIREMENT
INSPECTION
CRITERIA
PARAGRAPH
METHOD
REFERENCE
Critical
1
Primer above flush
100%
3.2.10
AIE
2
Ballistic test failure(projectile
4.4.1
3.5.2
4.4.1
safety)
Major
101
Fuze fails to withstand the required
Level IV
3.2.10
AIE/Torque
disassembly torque
test
102
Primer loose or missing
Level IV
3.2.10
Visual/Manual
103
Fuze setting incorrect
Level IV
3.2.10
Visual
104
Profile and diameter of mouth
100%
3.2.10
AIE/4.4.6
105
Ballistic test failure (functioning)
4.4.1.1
3.5.1
4.4.1.1
Minor
201
Gap between fuze & projectile
Level
II
3.2.10
Visual
202
Fuze not staked
Level
II
3.2.10
Visual
203
Rotating band damaged
Level
II
3.2.10
Visual
204
Marking missing, misleading or
Level
II
3.2.10
Visual
unidentifiable
205
Evidence of poor workmanship
Level II
3.6
Visual
25
