MIL-DTL-14997C (AR)
Conformance inspection by classification of characteristics
PARAGRAPH
TITLE
DRAWING NUMBER
4.3.2.13
Parachute assembly
SHEET 1 OF 1
9206766
NEXT HIGHER
ASSEMBLY
9206746
CLASSIFICATION
EXAMINATION OR TEST
CONFORMANCE
REQUIREMENT
INSPECTION
CRITERIA
PARAGRAPH
METHOD
REFERENCE
Critical
None defined
Major
None defined
Minor
201
Circumference of reinforcing band at
Level II
3.2
AIE
hem, min
202
Length of parachute cord from hem to
Level II
3.2
AIE
shroud wire
203
Variation in length of shroud wire
Level II
3.2
AIE
204
Any component missing or improperly
Level II
3.2
Visual
assembled
205
Stitching improper, missing or broken
Level II
3.2
Visual
206
Hole or tear in canopy (greater than
Level II
3.2
Visual
1/8 in dia. Or length)
207
Shroud not sewn minimum distance onto
Level II
3.2
Scale
radial tape
208
Crimp pull test
Level
II
3.2
Tension Tester
209
Overlap of tape, minimum
Level
II
3.2
AIE
210
Evidence of foreign matter
Level
II
3.5.1
Visual
211
Evidence of burr, sharp edges, and/or
Level
II
3.5.3
Visual
cracks
212
Evidence of damaged cloth
Level II
3.5.4
Visual
23
