MIL-DTL-14997C (AR)
Conformance inspection by classification of characteristics
PARAGRAPH
TITLE
DRAWING NUMBER
4.3.2.20
Plug, IR (M1064)
SHEET 1 OF 1
13020792
NEXT HIGHER
ASSEMBLY
13020794
CLASSIFICATION
EXAMINATION OR TEST
CONFORMANCE
REQUIREMENT
INSPECTION
CRITERIA
PARAGRAPH
METHOD
REFERENCE
Critical
None defined
Major
101
Outside diameter
Level
IV
3.2
AIE
102
Diameter at recess for base assembly
Level
IV
3.2
AIE
103
Depth of recess for base assembly
Level
IV
3.2
AIE
104
Length of step for fiberboard liner
Level
IV
3.2
AIE
105
Diameter at step for fiberboard liner
Level
IV
3.2
AIE
106
Distance to first stake notch
Level
IV
3.2
AIE
107
Distance to second stake notch
Level
IV
3.2
AIE
108
Distance to step for fiberboard liner
Level
IV
3.2
AIE
Minor
201
Evidence of foreign matter
Level II
3.5.1
Visual
202
Evidence of burr, sharp edges, and/or
Level II
3.5.3
Visual
cracks
30
